The FPV 3110 motor is a large-size, high-torque, low-kV external rotor brushless motor. It is not primarily designed for 5-inch racing drones that prioritize extreme speed and agility, but rather for models requiring strong pulling power and high efficiency. The FPV 3110 motor is a professional-grade motor built for power and endurance. It sacrifices an exceptional thrust-to-weight ratio and maneuverability in exchange for unparalleled efficiency and sustained thrust when driving large propellers. If your goal is to assemble an FPV drone capable of flying for more than 30 minutes or operating stably with heavy equipment, the 3110 motor is a classic and reliable choice.
| Specification | |
| Weight: | 85g (including the cables) |
| Motor Size: | 37.1 x 27mm |
| Shaft Diameter: | 5.0mm |
| Motor Mount: | 19*19mm(M3*4) |
| Configuration: | 12N14P |
| Motor Cable: | 16#AWG 300mm |
| FA3110KV 900KV Motor | |
| Max thrust：3600g | |
| Volts：25V(6S) | |
| Suggested ESC: 50A~60A | |
| Maximum Power：1410W | |
| Suggested Prop: HQ9050-3R, GF1050-3R prop | |
| ltem No. | Prop | Throttle | Volts | Amps | Watts | Speed | Thrust | Efficiency | Operating temperature(℃) |
| (V) | (A) | (W) | （RPM） | (g) | (g/W) | ||||
| FA3110 900KV | HQ9050-3R | 50% | 25 | 9.5 | 237.5 | 8475 | 1139 | 4.80 | 79.6℃ |
| 60% | 25 | 14.8 | 370.0 | 9780 | 1560 | 4.22 | |||
| 70% | 25 | 21.6 | 540.0 | 11008 | 1910 | 3.54 | |||
| 80% | 25 | 30.5 | 762.5 | 12187 | 2408 | 3.16 | |||
| 90% | 25 | 43.0 | 1075.0 | 13300 | 2936 | 2.73 | |||
| 100% | 25 | 50 | 1250.0 | 13535 | 3360 | 2.69 | |||
| FA3110 900KV | GF1050-3R | 50% | 25 | 10.3 | 257.5 | 8120 | 1301 | 5.05 | 75.3℃ |
| 60% | 25 | 15.8 | 395.0 | 9227 | 1712 | 4.33 | |||
| 70% | 25 | 23.2 | 580.0 | 10503 | 2210 | 3.81 | |||
| 80% | 25 | 33.3 | 832.5 | 11266 | 2655 | 3.19 | |||
| 90% | 25 | 45.2 | 1130.0 | 12543 | 2160 | 1.91 | |||
| 100% | 25 | 56.4 | 1410.0 | 13139 | 3600 | 2.55 |
