Name: Fury-Apex 2807
SKU: 1818
Rating: 5.00 (1 reviews)

This motor achieves excellent cruise efficiency, strong load capacity, and ample low-speed torque on larger drone platforms, prioritizing range, stability, and mission reliability over extreme maneuverability. It’s for Long-distance sailing enthusiasts, professional aerial photographers, and industry application developers.

Specification
Weight:	56.0g (including the cables)
Motor Size:	33.6 x 20mm
Shaft Diameter:	4.0mm
Motor Mount:	1919mm(M24)
Configuration:	12N14P
Motor Cable:	18#AWG 220mm

FA2807KV 1300KV Motor	FA2807KV 1500KV Motor	FA2807KV 1800KV Motor
Max thrust：1996g	Max thrust：2199g	Max thrust：1614g
Volts：24V(6S)	Volts：24V(6S)	Volts：16V(4S)
Suggested ESC: 40A~60A	Suggested ESC: 60A~70A	Suggested ESC: 50A~70A
Maximum Power：895.7W	Maximum Power：1098.8W	Maximum Power：636.1W
Suggested Prop: GF7043 inch prop	Suggested Prop: GF7043 inch prop	Suggested Prop: GF7043 inch prop

ltem No.	Volts(V)	Prop	Throttle	Current	Power	Thrust	PRM	Efficiency	Operating
ltem No.	Volts(V)	Prop	(%)	(A)	(W)	(g)	PRM	(g/W)	temperature(℃)
FA2807 1300KV	24.74	GF73.53	40%	9.91	245.2	817	13409	3.3	55.8℃
	24.65		50%	13.28	327.4	1012	14819	3.1
	24.54		60%	16.89	414.5	1202	16149	2.9
	24.42		70%	21.10	515.3	1410	17359	2.7
	24.25		80%	27.09	656.9	1680	19053	2.6
	24.05		90%	34.22	823.0	1942	20426	2.4
	23.94		100%	37.91	907.6	2036	20874	2.2
FA2807 1300KV	24.74	GF743	40%	9.41	232.8	780	14081	3.3	52.4℃
	24.65		50%	12.70	313.1	974	15467	3.1
	24.55		60%	16.16	396.7	1141	16663	2.9
	24.44		70%	20.00	488.8	1346	17818	2.8
	24.25		80%	26.36	639.2	1626	19326	2.5
	24.04		90%	33.79	812.3	1908	20673	2.3
	23.91		100%	37.46	895.7	1996	21083	2.2
FA2807 1300KV	24.71	GF7042	40%	10.03	247.8	793	12913	3.2	60.6℃
	24.62		50%	13.42	330.4	965	14327	2.9
	24.51		60%	17.33	424.8	1155	15577	2.7
	24.37		70%	22.12	539.1	1347	16867	2.5
	24.18		80%	28.87	698.1	1636	18311	2.3
	23.96		90%	36.35	870.9	1809	19495	2.1
	23.86		100%	40.03	955.1	1836	19797	1.9
ltem No.	Volts(V)	Prop	Throttle	Current	Power	Thrust	PRM	Efficiency	Operating
ltem No.	Volts(V)	Prop	(%)	(A)	(W)	(g)	PRM	(g/W)	temperature(℃)
FA2807 1500KV	24.66	GF73.53	40%	12.01	296.2	914	14100	3.1	66.5℃
	24.54		50%	16.24	398.5	1147	15699	2.9
	24.42		60%	20.55	501.8	1346	16989	2.7
	24.26		70%	26.14	634.2	1585	18352	2.5
	24.04		80%	33.57	807.0	1886	19924	2.3
	23.82		90%	41.48	988.1	2140	21280	2.2
	23.69		100%	45.79	1084.8	2239	21752	2.1
FA2807 1500KV	24.67	GF743	40%	11.70	288.6	878	14765	3.0	56.7℃
	24.55		50%	15.93	391.1	1090	16272	2.8
	24.44		60%	19.93	487.1	1287	17394	2.6
	24.29		70%	25.41	617.2	1533	18781	2.5
	24.08		80%	32.72	787.9	1840	20159	2.3
	23.82		90%	41.43	986.9	2098	21469	2.1
	23.68		100%	46.40	1098.8	2199	22084	2.0
FA2807 1500KV	24.64	GF7042	40%	12.34	304.1	908	13729	3.0	68.9℃
	24.52		50%	16.91	414.6	1126	15220	2.7
	24.38		60%	21.61	526.9	1318	16366	2.5
	24.21		70%	27.65	669.4	1555	17924	2.3
	23.98		80%	35.61	853.9	1792	19220	2.1
	23.73		90%	44.71	1061.0	1891	20099	1.8
	23.59		100%	49.34	1163.9	1938	20320	1.7
ltem No.	Volts(V)	Prop	Throttle	Current	Power	Thrust	PRM	Efficiency	Operating
ltem No.	Volts(V)	Prop	(%)	(A)	(W)	(g)	PRM	(g/W)	temperature(℃)
FA2807 1800KV	16.50	GF73.53	40%	11.95	197.2	683	12275	3.5	42℃
	16.40		50%	15.52	254.5	835	13516	3.3
	16.28		60%	19.34	314.9	980	14634	3.1
	16.18		70%	23.46	379.6	1128	15699	3.0
	16.00		80%	29.62	473.9	1337	17087	2.8
	15.78		90%	37.36	589.5	1555	18412	2.6
	15.65		100%	41.62	651.4	1658	18853	2.5
FA2807 1800KV	16.52	GF743	40%	11.31	186.8	646	12940	3.5	40.2℃
	16.42		50%	14.83	243.5	793	14185	3.3
	16.31		60%	18.46	301.1	931	15214	3.1
	16.21		70%	22.34	362.1	1072	16199	3.0
	16.03		80%	28.43	455.7	1280	17481	2.8
	15.81		90%	36.37	575.0	1519	18745	2.6
	15.68		100%	40.57	636.1	1614	19206	2.5
FA2807 1800KV	16.49	GF7042	40%	12.29	202.7	665	11904	3.3	41.3℃
	16.39		50%	15.94	261.3	804	13097	3.1
	16.28		60%	19.80	322.3	939	14146	2.9
	16.15		70%	24.37	393.6	1091	15178	2.8
	15.95		80%	31.39	500.7	1307	16558	2.6
	15.70		90%	39.72	623.6	1516	17697	2.4
	15.59		100%	43.78	682.5	1590	18236	2.3
